Bergmann HTW 65 S V1.0.0.0
Bergmann HTW 65 S V1.0.0.0
The BERGMANN HTW 65 S is a high-performance forage transport wagon designed for the rapid and cost-effective transport of grass and maize silage, as well as other chopped crops and biomass.
Its tridem chassis, featuring 300 mm hydraulic axle compensation, ensures excellent stability and off-road capability.
The combination of a conical cargo space, four robust floor conveyor chains, and two metering rollers enables fast, uniform unloading—allowing the wagon to be completely emptied in under a minute.
Technical details:
Weights
Permissible gross weight: 33,000 – 34,000 kg
Unladen weight (basic configuration): 10,900 kg
Drive
PTO input speed: 1,000 rpm
Body / Cargo space
Price: 99.500$
Payload: 22,100 – 23,100 kg
Loading volume: 56.4 m³
Number of metering rollers: 2
Metering roller diameter: 380 mm
Conveyor floor
Number of conveyor floor chains: 4
Chain link dimensions: 14 x 50 mm
Max. breaking load per chain (total): 25 (100) t
Unloading speed at 1,000 rpm: 16.3 m/min
Running gear
Tridem chassis with forced steering (first axle: lift axle)
Transport speed: 40 km/h
Tractor requirements
Engine power (min. – max.): 154 – 294 / 210 – 400 kW/hp
Required control valves (single-acting): 1
Required control valves (double-acting): 3
What was done:
Added cameras based on real-world features (requires Mercedes-Benz Trucks Pack), as well as tractors capable of displaying them—such as those by Paul.
Installed BPW hubs
Added Warnstripes
